| EIA | PN | Rated voltage |
Leakage current |
Trigger voltage |
Clamping voltage |
Capacitance | ESD Contact discharge |
ESD Air discharge |
ESD pulse withstand |
||
| VDC | IL | Vt | Vc | Cp | KV | KV | |||||
| max | Typ | Type | Type | Condition | Type | Max | Type | Type | times | ||
| 0402 | EGA10402V05AM | 5 | 0.01 | 300 | 30 | 1MHz | 0.2 | 8 | 15 | 1000 | |
| 0402 | EGA10402V12AM | 12 | 0.01 | 300 | 30 | 1MHz | 0.2 | 8 | 15 | 1000 | |
| 0402 | EGA10402V24AM | 24 | 0.01 | 300 | 30 | 1MHz | 0.2 | 8 | 15 | 1000 | |
| 0603 | EGA10603V05AM | 5 | 0.01 | 300 | 30 | 1MHz | 0.2 | 8 | 15 | 1000 | |
| 0603 | EGA10603V12AM | 12 | 0.01 | 300 | 30 | 1MHz | 0.2 | 8 | 15 | 1000 | |
| 0603 | EGA10603V24AM | 24 | 0.01 | 300 | 30 | 1MHz | 0.2 | 8 | 15 | 1000 | |
